Products
HOME Products CABLE Assembly

CABLE Assembly

PIN Jack Plug

Cable ass'y

Cable ass'y
Pin Plug
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

P050050_FL

Steel

SnCu

Cable ass'y
Cable ass'y

Cable ass'y
Pin Plug
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

P200030_FL

Steel

SnCu

Cable ass'y
Cable ass'y

Cable ass'y
Pin Plug
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

P760010_FL

Steel

SnCu

Cable ass'y
Cable ass'y

Cable ass'y
Pin Plug
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

P820050_FL

Steel

SnCu

Cable ass'y
Cable ass'y

Cable ass'y
Mini Pin Plug
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

PS010030_FL

Steel

SnCu

Cable ass'y

Cable ass'y
Mini Pin Plug
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

PS020030_FL

Steel

SnCu

Cable ass'y

F Connector

Cable ass'y

Cable ass'y
Screw portion Circle
Crimp type
VSWR:~1GHz
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

F030010_FL

Bs

Ni

Cable ass'y

Cable ass'y
Screw portion H cut
Crimp type
VSWR:~1GHz
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

F031010_FL

Bs

Ni

Cable ass'y

F plug

Cable ass'y

Cable ass'y
Push-on type
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

DS055011_FL

PB

Ni

Cable ass'y
Cable ass'y

Cable ass'y
Push-on type
Solder type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

DS055021_FL

PB

Ni

Cable ass'y
Cable ass'y

Cable ass'y
Screw type
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

FP120011_FL

Bs

Ni

Cable ass'y

IEC Connector

Cable ass'y

Cable ass'y
"IEC" Plug
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

DP022021_FL

Bs

Ni

Cable ass'y
Cable ass'y

Cable ass'y
"IEC" Plug
Solder type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

DP022041_FL

Bs

Ni

Cable ass'y
Cable ass'y

Cable ass'y
"IEC" Socket
Crimp type
Cable type:1.5C-2V 1.7C-2V

Part No.

Material of Shell

Plating

DS054041_FL

PB

Ni

Cable ass'y

SMA Connector

Cable ass'y

Cable ass'y
SMA Plug
Solder type
Cable type:SF085, UT085

Part No.

Material of Shell

Plating

SMA020011_FL

Bs

Au

SMA020021_FL

Bs

Ni

Cable ass'y
Cable ass'y

Cable ass'y
SMA Plug
Solder type
Cable type:SF085, UT085

Part No.

Material of Shell

Plating

SMA051010_FL

Bs

Au

Cable ass'y
Cable ass'y

Cable ass'y
SMA Plug
Crimp type
Cable type:1.5D-2V , 3D-2V

Part No.

Material of Shell

Plating

SMA140011_FL

Bs

Au

SMA141011_FL

Bs

Au

Cable ass'y
Cable ass'y

Cable ass'y
SMA Jack
Solder type
Cable type:SF085, UT085

Part No.

Material of Shell

Plating

SMA180011_FL

Bs

Ni

Cable ass'y
Cable ass'y

Cable ass'y
SMA Plug
Solder type
Cable type:SF085, UT085

Part No.

Material of Shell

Plating

SMA06011_FL

Bs

Au

Cable ass'y

SMB Connector

Cable ass'y

Cable ass'y
SMB Plug
Solder type
Cable type:SF085

Part No.

Material of Shell

Plating

SMB020011_FL

Bs

SnCu

Cable ass'y
Cable ass'y

Cable ass'y
SMB Plug
Crimp type
Cable type:1.5D-2V

Part No.

Material of Shell

Plating

SMB020021_FL

Bs

Ni

Cable ass'y
Cable ass'y

Cable ass'y
SMB Plug
Solder type
Cable type:SF085

Part No.

Material of Shell

Plating

SMB050010_FL

Bs

SnCu

Cable ass'y
Cable ass'y

Cable ass'y
SMB Plug
Crimp type
Cable type:1.5D-2V

Part No.

Material of Shell

Plating

SMB100021_FL

Bs

Ni

Cable ass'y
Cable ass'y

Cable ass'y
SMB Jack
Solder type
Cable type:SF085, UT085

Part No.

Material of Shell

Plating

SMA180011_FL

Bs

Ni

Cable ass'y

SP Connector

Cable ass'y

Cable ass'y
SP Pin Plug
Crimp type
Cable type:1.5C-2V 1.7C-2V
       1.5D-2V

Part No.

Material of Shell

Plating

SP060021

Bs

Ag

SP060031

Bs

Au

Cable ass'y

Others

Cable ass'y

Cable ass'y
Board in Plug
Crimp type
Cable type:1.5C-2V 1.7C-2V
       1.5D-2V

Part No.

Material of Shell

Plating

SMB120011_FL

Steel

SnCu

Cable ass'y
2ホールレセプタクル

Cable ass'y
2 Hole receptacle
Crimp & solder type
Cable type:SF085

Part No.

Material of Shell

Plating

T-293

Bs

SnCu

Cable ass'y
TNC

Cable ass'y
TNC Jack
Crimp type
Cable type:1.5D-2V

Part No.

Material of Shell

Plating

TNC010010_FL

Bs

Ni

Cable ass'y
